7 ways to Query Always On Availability Groups using SQL

chrome

There are multiple ways to query availability group information, below are some of my favourite goto queries when I need to obtain information about Always on Availability groups for various tasks.

Show All availability groups visible to this server where this Server is the Primary replica

SELECT Groups.[Name] AS AGname
FROM sys.dm_hadr_availability_group_states States
INNER JOIN master.sys.availability_groups Groups ON States.group_id = Groups.group_id
WHERE primary_replica = @@Servername;

Show All availability groups visible to this server where this Server is a Secondary replica

SELECT Groups.[Name] AS AGname
FROM sys.dm_hadr_availability_group_states States
INNER JOIN master.sys.availability_groups Groups ON States.group_id = Groups.group_id
WHERE primary_replica != @@Servername;

Show All Databases in an availability group visible to this server where this Server is the primary replica

SELECT
Groups.[Name] AS AGname,
AGDatabases.database_name AS Databasename
FROM sys.dm_hadr_availability_group_states States
INNER JOIN master.sys.availability_groups Groups ON States.group_id = Groups.group_id
INNER JOIN sys.availability_databases_cluster AGDatabases ON Groups.group_id = AGDatabases.group_id
WHERE primary_replica = @@Servername
ORDER BY
AGname ASC,
Databasename ASC;

Show All Databases in an availability group visible to this server where this Server is a Secondary replica

SELECT
Groups.[Name] AS AGname,
AGDatabases.database_name AS Databasename
FROM sys.dm_hadr_availability_group_states States
INNER JOIN master.sys.availability_groups Groups ON States.group_id = Groups.group_id
INNER JOIN sys.availability_databases_cluster AGDatabases ON Groups.group_id = AGDatabases.group_id
WHERE primary_replica != @@Servername
ORDER BY
AGname ASC,
Databasename ASC;

Show All Databases Across all Availability groups within the Cluster (not specific to current server)

SELECT  Groups.[name] AS AGName ,
Databaselist.[database_name] AS DatabaseName
FROM    sys.availability_databases_cluster Databaselist
INNER JOIN sys.availability_groups_cluster Groups ON Databaselist.group_id = Groups.group_id
ORDER BY
AGName ,
DatabaseName;

Show Availability groups visible to the Server and Replica information such as Which server is the Primary replica, Sync and Async modes , Readable Secondary and Failover Mode

--Show Availability groups visible to the Server and Replica information such as Which server is the Primary
--Sync and Async modes , Readable Secondary and Failover Mode, these can all be filtered using a Where clause
--if you are running some checks, no Where clause will show you all of the information.
WITH AGStatus AS(
SELECT
name as AGname,
replica_server_name,
CASE WHEN  (primary_replica  = replica_server_name) THEN  1
ELSE  '' END AS IsPrimaryServer,
secondary_role_allow_connections_desc AS ReadableSecondary,
[availability_mode]  AS [Synchronous],
failover_mode_desc
FROM master.sys.availability_groups Groups
INNER JOIN master.sys.availability_replicas Replicas ON Groups.group_id = Replicas.group_id
INNER JOIN master.sys.dm_hadr_availability_group_states States ON Groups.group_id = States.group_id
)

Select
[AGname],
[Replica_server_name],
[IsPrimaryServer],
[Synchronous],
[ReadableSecondary],
[Failover_mode_desc]
FROM AGStatus
--WHERE
--IsPrimaryServer = 1
--AND Synchronous = 1
ORDER BY
AGname ASC,
IsPrimaryServer DESC;

The code below is originally from the AG Dashboard that can be found in SSMS,I have adapted the code to show some human friendly columns and alter the logic slightly to take a single Parameter @AGname , SET to NULL to see all AG’s or set to a specific AG for a filtered list , this is a condensed version of the AG Dashboard which contains a horde of information such as Redo queue sizes, rates Estimated Data Loss and LSN information.


SET NOCOUNT ON;

DECLARE @AGname NVARCHAR(128);

DECLARE @SecondaryReplicasOnly BIT;

SET @AGname = 'AG1';	    --SET AGname for a specific AG for SET to NULL for ALL AG's

IF OBJECT_ID('TempDB..#tmpag_availability_groups') IS NOT NULL
DROP TABLE [#tmpag_availability_groups];

SELECT *
INTO [#tmpag_availability_groups]
FROM   [master].[sys].[availability_groups];

IF(@AGname IS NULL
OR EXISTS
(
SELECT [Name]
FROM   [#tmpag_availability_groups]
WHERE  [Name] = @AGname
))
BEGIN

IF OBJECT_ID('TempDB..#tmpdbr_availability_replicas') IS NOT NULL
DROP TABLE [#tmpdbr_availability_replicas];

IF OBJECT_ID('TempDB..#tmpdbr_database_replica_cluster_states') IS NOT NULL
DROP TABLE [#tmpdbr_database_replica_cluster_states];

IF OBJECT_ID('TempDB..#tmpdbr_database_replica_states') IS NOT NULL
DROP TABLE [#tmpdbr_database_replica_states];

IF OBJECT_ID('TempDB..#tmpdbr_database_replica_states_primary_LCT') IS NOT NULL
DROP TABLE [#tmpdbr_database_replica_states_primary_LCT];

IF OBJECT_ID('TempDB..#tmpdbr_availability_replica_states') IS NOT NULL
DROP TABLE [#tmpdbr_availability_replica_states];

SELECT [group_id],
[replica_id],
[replica_server_name],
[availability_mode],
[availability_mode_desc]
INTO [#tmpdbr_availability_replicas]
FROM   [master].[sys].[availability_replicas];

SELECT [replica_id],
[group_database_id],
[database_name],
[is_database_joined],
[is_failover_ready]
INTO [#tmpdbr_database_replica_cluster_states]
FROM   [master].[sys].[dm_hadr_database_replica_cluster_states];

SELECT *
INTO [#tmpdbr_database_replica_states]
FROM   [master].[sys].[dm_hadr_database_replica_states];

SELECT [replica_id],
[role],
[role_desc],
[is_local]
INTO [#tmpdbr_availability_replica_states]
FROM   [master].[sys].[dm_hadr_availability_replica_states];

SELECT [ars].[role],
[drs].[database_id],
[drs].[replica_id],
[drs].[last_commit_time]
INTO [#tmpdbr_database_replica_states_primary_LCT]
FROM   [#tmpdbr_database_replica_states] AS [drs]
LEFT JOIN [#tmpdbr_availability_replica_states] [ars] ON [drs].[replica_id] = [ars].[replica_id]
WHERE  [ars].[role] = 1;

SELECT [AG].[name] AS [AvailabilityGroupName],
[AR].[replica_server_name] AS [AvailabilityReplicaServerName],
[dbcs].[database_name] AS [AvailabilityDatabaseName],
ISNULL([dbcs].[is_failover_ready],0) AS [IsFailoverReady],
ISNULL([arstates].[role_desc],3) AS [ReplicaRole],
[AR].[availability_mode_desc] AS [AvailabilityMode],
CASE [dbcs].[is_failover_ready]
WHEN 1
THEN 0
ELSE ISNULL(DATEDIFF([ss],[dbr].[last_commit_time],[dbrp].[last_commit_time]),0)
END AS [EstimatedDataLoss_(Seconds)],
ISNULL(CASE [dbr].[redo_rate]
WHEN 0
THEN-1
ELSE CAST([dbr].[redo_queue_size] AS FLOAT) / [dbr].[redo_rate]
END,-1) AS [EstimatedRecoveryTime_(Seconds)],
ISNULL([dbr].[is_suspended],0) AS [IsSuspended],
ISNULL([dbr].[suspend_reason_desc],'-') AS [SuspendReason],
ISNULL([dbr].[synchronization_state_desc],0) AS [SynchronizationState],
ISNULL([dbr].[last_received_time],0) AS [LastReceivedTime],
ISNULL([dbr].[last_redone_time],0) AS [LastRedoneTime],
ISNULL([dbr].[last_sent_time],0) AS [LastSentTime],
ISNULL([dbr].[log_send_queue_size],-1) AS [LogSendQueueSize],
ISNULL([dbr].[log_send_rate],-1) AS [LogSendRate_KB/S],
ISNULL([dbr].[redo_queue_size],-1) AS [RedoQueueSize_KB],
ISNULL([dbr].[redo_rate],-1) AS [RedoRate_KB/S],
ISNULL(CASE [dbr].[log_send_rate]
WHEN 0
THEN-1
ELSE CAST([dbr].[log_send_queue_size] AS FLOAT) / [dbr].[log_send_rate]
END,-1) AS [SynchronizationPerformance],
ISNULL([dbr].[filestream_send_rate],-1) AS [FileStreamSendRate],
ISNULL([dbcs].[is_database_joined],0) AS [IsJoined],
[arstates].[is_local] AS [IsLocal],
ISNULL([dbr].[last_commit_lsn],0) AS [LastCommitLSN],
ISNULL([dbr].[last_commit_time],0) AS [LastCommitTime],
ISNULL([dbr].[last_hardened_lsn],0) AS [LastHardenedLSN],
ISNULL([dbr].[last_hardened_time],0) AS [LastHardenedTime],
ISNULL([dbr].[last_received_lsn],0) AS [LastReceivedLSN],
ISNULL([dbr].[last_redone_lsn],0) AS [LastRedoneLSN]
FROM   [#tmpag_availability_groups] AS [AG]
INNER JOIN [#tmpdbr_availability_replicas] AS [AR] ON [AR].[group_id] = [AG].[group_id]
INNER JOIN [#tmpdbr_database_replica_cluster_states] AS [dbcs] ON [dbcs].[replica_id] = [AR].[replica_id]
LEFT OUTER JOIN [#tmpdbr_database_replica_states] AS [dbr] ON [dbcs].[replica_id] = [dbr].[replica_id]
AND [dbcs].[group_database_id] = [dbr].[group_database_id]
LEFT OUTER JOIN [#tmpdbr_database_replica_states_primary_LCT] AS [dbrp] ON [dbr].[database_id] = [dbrp].[database_id]
INNER JOIN [#tmpdbr_availability_replica_states] AS [arstates] ON [arstates].[replica_id] = [AR].[replica_id]
WHERE  [AG].[name] = ISNULL(@AGname,[AG].[name])
ORDER BY [AvailabilityReplicaServerName] ASC,
[AvailabilityDatabaseName] ASC;

/*********************/

END;
ELSE
BEGIN
RAISERROR('Invalid AG name supplied, please correct and try again',12,0);
END;

Have fun querying and thanks for reading 🙂
